Mondraker custom desing Fidlock smoked transparent 600ml bottle + Fidlock base down version *Optional external battery: TQ 160Wh
Das NEAT RR kommt mit einer Fox 36 29 Float GRIP2 Factory Kashima Gabel, SRAM GX Eagle AXS Antrieb, SRAM Level Bronze Stealth Bremsen, Fox Transfer Factory Kashima Dropper Post und Mavic E-DeeMax SL 29 Laufrädern.
: Mondraker custom desing Fidlock smoked transparent 600ml bottle + Fidlock base down version *Optional external battery: TQ 160Wh
Schaltung: Sram GX Eagle AXS T-Type,12s
Kurbel: E.13 Helix Core E*Spec Plus, All sizes: 160mm
Rahmenmaterial: Carbon
Gewicht (kg): 18.7
Gabel: Fox 36 29 Float GRIPX2 Factory Kashima, 160mm, tapered steerer tube, Boost 15x110mm Kabolt axle, 44mm offset. Settings: high and low-speed compression, high and low-speed rebound, air preload
Bremssystem: Shimano XT M8120, 4 piston caliper, MT800 ICE-Tech 203mm CenterLock rotor, resin pads with fin
Nabe: Mavic Infinity hub, ID360 freewheel technology, Boost 12x148mm, IS 6 bolts XD freehub
Felgen: Mavic E-CrossTrail SL, 29 Boost 30mm internal width, hookless, tubeless ready, 28 spokes
Dämpfer: Fox Float X Factory Kashima EVOL, 185x55mm. Settings: 2-position compression (Open/Firm), rebound, air preload. Trunnion top mount, 30x8mm bottom bushings
Akkuleistung: TQ HPR-50 360Wh integrated and removable
Motor: TQ HPR-50
Reifen: Maxxis Minion DHF 29x2.5 WT, tubeless ready, 3C MAXX GRIP compound, EXO+ protection, 60TPI, folding bead / Maxxis Minion DHR II 29x2.5 WT, tubeless ready, 3C MAXX TERRA compound, EXO+ protection, 60TPI, folding bead
Kette: Sram GX Eagle T-Type, 12s, Powerlock
Kassette: Sram XS-1275, 10-52T, T-Type, 12s
Schaltwerk: Sram GX Eagle AXS T-Type,12s
Schalthebel: Sram Eagle AXS Pod MMX, 12s
Lenker: Onoff S6 1.0 7050 alloy, rise: 25mm, width: 800mm, 8º backsweep, 5º upsweep, 31.8mm barbore. L and XL size: 1.5 rise.
Griffe: Onoff Forest, CNC lock-on, 135mm
Vorbau: Onoff S6 30mm 0º, 6061 forged alloy + CNC, 31.8mm barbore
Sattel: Fizik Terra Aidon Slim X5
Sattelstütze: Fox Transfer Factory Kashima internal, adjustable travel, diameter 31.6mm,S size: 95mm -120mm, M size: 125mm -150mm, L size: 155mm -180mm, XL size: 185mm -210mm
Dämpfer: Fox Float X Factory Kashima EVOL, 185x55mm. Settings: 2-position compression (Open/Firm), rebound, air preload. Trunnion top mount, 30x8mm bottom bushings
Antrieb: TQ HPR-50
Rahmen: Stealth Air full Carbon, Updated Zero Suspension System, 150mm travel, Forward Geometry, internal & removable battery, Boost 12x148mm rear axle, tapered head tube, one-piece Monoblock upper link, HHG internal cable routing, MAX capacity sealed bearings, oversize 15mm axles, integrated dropout speed sensor, exclusive plastic motor covers.
Steuersatz: Acros custom IS52/ZS56, 1-1/8", 1.5" head tube, Internal cable routing, sealing plugs without blocklock
Nabe vorne: Mavic Infinity hub, Boost 15x110mm, IS 6 bolts
