Sram UDH
Mondraker custom desing Fidlock smoked transparent 600ml bottle + Fidlock base down version *Optional external battery: TQ 160Wh
Das NEAT R kommt mit einer Fox 36 29 Float GRIP EVOL Performance Gabel, SRAM GX Eagle Antrieb, SRAM G2 R Bremsen, ONOFF Pija Dropper Post und Mavic E-Crossride 29 Laufrädern.
: Mondraker custom desing Fidlock smoked transparent 600ml bottle + Fidlock base down version *Optional external battery: TQ 160Wh
: Sram UDH
Schaltung: Sram S1000 Eagle AXS T-Type, 12s
Kurbel: E.13 Helix Core E*Spec Plus, All sizes: 160mm
Rahmenmaterial: Carbon
Gewicht (kg): 18.9
Gabel: RockShox LYRIK Select Charger RC 29, 160mm, e-bike approved, tapered steerer tube, Boost 15x110mm axle, 44mm offset. Settings: low-speed compression, low-speed rebound, air preload
Bremssystem: Sram DB8 stealth, 4-piston caliper, Centerline 200mm IS 6 bolts one-piece rotor, steel-backed organic pads
Nabe: Mavic, Boost 12x148mm, ID360 Ratched system, IS 6 bolts, HG freehub
Felgen: Mavic E-CrossRide 29, 30mm internal width, welded, PFP, tubeless ready, 28 spokes
Dämpfer: Rock Shox Super Deluxe Select, 185x55mm, Settings: 2-position compression (Open/Firm), rebound, air preload. Trunnion top mount, 30x8mm bottom bushings
Akkuleistung: TQ HPR-50 360Wh integrated and removable
Motor: TQ HPR-50
Reifen: Maxxis Minion DHF 29x2.5 WT, tubeless ready, 3C MAXX GRIP compound, EXO+ protection, 60TPI, folding bead / Maxxis Minion DHR II 29x2.5 WT, tubeless ready, 3C MAXX TERRA compound, EXO+ protection, 60TPI, folding bead
Kette: Sram GX Eagle T-Type, 12s, Powerlock
Kassette: Sram XS-1270, 10-52T, T-Type, 12s
Schaltwerk: Sram S1000 Eagle AXS T-Type, 12s
Schalthebel: Sram Eagle AXS Pod MMX, 12s
Lenker: Onoff S3 1.0 6061 alloy, rise: 25mm, width: 800mm, 8º backsweep, 5º upsweep, 31.8mm barbore. L and XL size: 1.5 rise.
Griffe: Onoff Forest, CNC lock-on, 135mm
Vorbau: Onoff S3 30mm 0º, 6061 forged alloy, 31.8mm barbore
Sattel: Fizik Terra Aidon Slim X5
Sattelstütze: Onoff Pija dropper internal, diameter 31.6mm, 1X Remote lever with bearing, S size: 140-115mm (388-235mm), M size: 160-135mm (428-255mm), L size: 180-155mm (468-275mm), XL size: 210-185mm (528-305mm)
Dämpfer: Rock Shox Super Deluxe Select, 185x55mm, Settings: 2-position compression (Open/Firm), rebound, air preload. Trunnion top mount, 30x8mm bottom bushings
Antrieb: TQ HPR-50
Rahmen: Stealth Air full Carbon, Updated Zero Suspension System, 150mm travel, Forward Geometry, internal & removable battery, Boost 12x148mm rear axle, tapered head tube, one-piece Monoblock upper link, HHG internal cable routing, MAX capacity sealed bearings, oversize 15mm axles, integrated dropout speed sensor, exclusive plastic motor covers.
Steuersatz: Acros custom IS52/ZS56, 1-1/8", 1.5" head tube, Internal cable routing, sealing plugs without blocklock
Nabe vorne: Mavic, Boost 15x110mm, IS 6 bolts
